22/16 MC

Model:	22/16 MC CE (ATEX EX II 2G c T4)
Pressure Ratio:	16:1
Flow rate:	22 liters/min. open outlet with water and at 5 bars with 3/8” outlet
MC:	single-component
Pressure < supply:	1 bar
Pressure > supply:	6 bar
Air Consumption:	6 bar and, at 10 cycles per minute, 200 liters
Air supply inlet:	da 3/8 / 1/2"
Cubic capacity per cycle:	212 cc
Maximum cycles recommended:	16 al 1’

Technical notes

- The pump can work without any pressure drop up to 15 complete cycles per minute (30 strokes)
- The pneumatic motor is in aluminum, diam. 200 mm with a stroke of 54 mm; it uses 200 liters of air at 6 bar and 10 cycles per minute.
- Product outlet available both 3/8“ and 1/2" upon request.
- Stainless intake manifold, pipe diameter 22 mm with 3/4" joint



NOTE:

the pump is suitable for product transfer
